Ubiquiti UniFi Access Point AC Long Range (UAP-AC-LR)
The UniFi AC LR AP features the latest Wi-Fi 802.11ac technology in a refined industrial design and is ideal for long-range deployment of high-performance wireless networks. Dual-Radio Performance, Gigabit Speeds The UniFi AC Long Range delivers 5x the performance of the first-generation UniFi AP while still maintaining Ubiquiti’s disruptive pricing strategy. The UniFi AC Long […]
The UniFi AC LR AP features the latest Wi-Fi 802.11ac technology in a refined industrial design and is ideal for long-range deployment of high-performance wireless networks.
Dual-Radio Performance, Gigabit Speeds
The UniFi AC Long Range delivers 5x the performance of the first-generation UniFi AP while still maintaining Ubiquiti’s disruptive pricing strategy.
The UniFi AC Long Range can work with wireless data transfer up to 1317 Mbps, standard 802.11a/b/g/n/ac is supported, UniFi uses MIMO 3×3 antennas system 3dBi. The signal range is up to 183 m.
Innovative Antenna Design
The innovative antenna design provides a long-range, symmetrical-link coverage area, and the antenna gain of the UniFi AC LR AP performs better than one-way, high transmit power does for connecting distant clients.
Scalable Enterprise Wi-Fi Management
The UniFi Controller v4 software is a powerful, enterprise wireless software engine ideal for high-density client deployments requiring low latency and high uptime performance. With its software-based capabilities, the UniFi virtual control plane allows for unlimited scalability under one centralized controller. Remotely access the UniFi Controller to upgrade deployed UniFi APs while in the field.
Specification:
| Dimensions | 160 x 160 x 31.45 mm (6.30 x 6.30 x 1.24″) |
| Weight With Mounting Kits |
170 g (6.0 oz) 185 g (6.5 oz) |
| Networking Interface | 10/100/1000 Ethernet Port |
| Buttons | Reset |
| Power Method | 802.3af/A PoE 24V Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Power Supply | 24V, 0.5A Gigabit PoE Adapter* |
| Power Save | Supported |
| Maximum Power Consumption | 6.5W |
| Maximum TX Power 2.4 GHz 5 GHz |
20 dBm 20 dBm |
| Antennas | (2) Dual‑Band Antennas, 3 dBi Each |
| Wi-Fi Standards | 802.11 a/b/g/n/ac |
| Wireless Security | WEP, WPA‑PSK, WPA‑Enterprise (WPA/WPA2, TKIP/AES) |
| BSSID | Up to 8 per Radio |
| Mounting | Wall/Ceiling (Kits Included) |
| Operating Temperature | ‑10 to 70° C (14 to 158° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
| Supported Data Standarts | 802.11ac/n/a/g/b |
* Only the single‑pack of the UAP‑AC‑LITE includes a PoE adapter.
Advanced Traffic Management
| VLAN | 802.1Q |
| Advanced QoS | Per‑User Rate Limiting |
| Guest Traffic Isolation | Supported |
| WMM | Voice, Video, Best Effort, and Background |
| Concurrent Clients | 250+ |
